Reconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End Hose

Achieve Innovations (Changsha) Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Reconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End Hose

Brand Name : ZOOMLION

Model Number : 47X-5RZ

Place of Origin : Hunan, China

MOQ : 1

Price : USD76,000 FOB China

Payment Terms : L/C, T/T

Supply Ability : 10 units per month

Delivery Time : 15 DAYS

Packaging Details : Export Standard

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Warranty : 3 Months

After Warranty Service : Video technical support, Online support, Spare parts

Distribution valve : S valve

Horizontal distance : 42.7

Contact Now

Reconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End HoseReconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End Hose

• Compact in design, 47m pump mounted on a 3-axle truck.
• Boom intelligent damping technology:The soft control of booms in starting, slewing and stopping reduces the impacting vibration of booms and therefore makes the vehicle operate more stably,
reliably and safely.

Accurate pumping control technology(APC):Great leap of pumping accuracy and adaptability, improving pump efficiency.

• Adaptive concrete material pumping technology: Improve pumping control system for poor concrete with segregation and big viscosity, and auto-adaptive pumping mode, reducing the block rate by more than 50%.Reconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End Hose

Main Parameters

Model ZLJ5339THB 47X-5RZ
Pumping system Max. Theor. output m3/h 170/120
Max. Theor. concrete output Pressure MPa 8.3/12
Rated working pressure MPa 35
Pumping frequency min-1 25/18.5
Hopper capacity L 600
Filling height 1540
Hydraulic system type Open loop
Distribution valve S valve
Oil cylinder dia.×stroke mm Φ150×2100
Concrete cylinder dia.×stroke mm Φ260×2100
Hydraulic oil cooling Air cooling
Recommended concrete slump cm 12~23
Max. aggregate dimension mm 40
Placing boom Structure type 47X-5RZ
Placing depth m 47
Horizontal distance m 42.7
Placing depth m 33.4
Slewing angle ±270°
Boom number 5
The length of boom section mm 9380/8130/7930/8610/8950
Sections folding angle 90°/180°/180°/240°/180°
Pipe diameter mm 125
End hose length mm 3000
Min. height of opening placing boom mm 9700
Outriggers span (front×rear×side) mm 9310×9675×9420
Chassis and the whole machine Chassis model ACTROS 3341 6×4
Wheelbase mm 4500+1350
Engine type OM501LA
Engine power kW/(r/min) 300/1800
Engine moment N.m/(r/min) 2000/1080
Maximum displacement cc 11946
Oil tank cubage L 400
Tail gas exhaust standard 欧Ⅳ
Total weight kg 34000
Overall dimensions mm 12020×2500×4000
Others Lubrication mode Automatic lubrication
Oil tank volume L 780
Control mode Manual+remote control
Maximum water pressure MPa 7
Water tank volume L 400
Pipe cleaning mode Water cleaning/dry cleaning

Reconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End Hose

Achieve is located in Changsha, China,

The same city as ZOOMLION & SANY.

We supply TOP QUALITY refurbished concrete pumps to our customers overseas.

Brand: ZOOMLION, Putzmeister, SANY, XCMG, JUNJIN etc.Reconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End Hose

Refurbishing quality is our first concern.Achieve Innovations (Changsha) Co.,Ltd.
. A leading Supplier in the Concrete Machinery Industry for Premium quality China-made Products
. Specializing in Concrete Machinery, Used Concrete Pumps, Concrete Batching Plants, Mortar Pump, Tailor-made Equipment & Parts
. We are a professional team, with more than 15 years of experience in this industry.

Reconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End Hose

Reconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End Hose

Reconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End HoseReconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End HoseReconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End HoseReconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End Hose

Reconditioned Zoomlion 47X-5RZ Concrete Pump Truck Pumping System End Hose

Q1:Are you a manufacture or a trading company?

A1:We are a trading company since 2018 year.
Q2:What is your advantage? - More than a decade,We have been focusing on concrete pump since.
A2:-Professionally and Highly remanufactured standard for used concrete pump machines
-Providing competitive price for customer.
-Professional sales service availably.
Q3:What is your main products?
A3:Truck-mounted concrete pump, Concrete pump truck , Concrete line pump ,Concrete mixer truck, and Concrete pump spare parts, Crane and Lubricate oil .we have the whole series products you need.
Q4:What kind terms of payment can be accepted? A4:Normally we can work on T/T term or L/C term.
Q5:What about the delivery time?
A5:7-30 days after receving the deposit.
Q6:What about the warranty time?
A6:12 months after shipment or 2000 working hours.
Q7:What about the Minimum Order Quantity?
A7:The MOQ is 1 pcs.
