Refurbishing ZOOMLION 47M Concrete Pump Mercedez Benz Chassis

Name: Refurbishing ZOOMLION 47M Concrete Pump Mercedez Benz Chassis
Brand: ZOOMLION
Price: 200 USD

Quality Refurbishing ZOOMLION 47M Concrete Pump Mercedez Benz Chassis wholesale

Brand Name : ZOOMLION

Model Number : ZLJ5336THB 47X-5RZ

Place of Origin : HUNAN, CHINA

MOQ : 1 unit

Price : USD200,000 FOB CHINA

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 4 units per month

Delivery Time : 45 days after order confirmation

Packaging Details : Bulk

Vertical Reach : 47m

Chassis : Mercedez Benz

Production Year : 2012

Condition : Refurbished

Contact Now

Brand New ZOOMLION Truck Mounted Pumps 47X-5RZ

The structural strength and stiffness of the sections ensure limited oscillations even on longer booms. The working speed, guarantees the complete extension of the boom and its perfect positioning within few minutes.

最大理论输送量Max. Theor. output m³/h	120/70
混凝土最大出口压力Max. Theor. concrete output Pressure MPa	7/11
额定工作压力 Rated working pressure MPa	35
泵送频率Pumping frequency min^-1	22/13
料斗容积Hopper capacity L	550
上料高度Filling height mm	1540
液压系统型式Hydraulic system type	闭式 Close loop
分配阀形式Distribution valve	S管阀 S valve
油缸缸径×行程 Oil cylinder dia.×stroke mm	φ130×2100
混凝土缸径×行程Concrete cylinder dia.×stroke mm	φ230×2100
液压油冷却Hydraulic oil cooling	风冷 Air cooling
推荐塌落度Recommended concrete slump cm	12~23
最大骨料尺寸Max. aggregate dimension mm	40

Model		Unit	47X-5RZ
Pump Unit	Maximum theorical output	m3/h	180/120
	Maximum pressure on concrete	bar	80/120
	Conc. cylinders (diam. x stroke)	mm	260x2100
	Concrete hopper capacity	L	600
	Hydraulic circuit		Open
Boom Section	Maximum vertical reach	m	47
	Maximum horizontal distance	m	42.7
	Minimum unfolding height	m	9.7
	Section numbers		5
	Rotating angle		±270°
	End hose lenght	m	3
